3. Future climate projected by CGCM2.3.2

FigureA3.4

Figure A3.4 Time series of projected global mean sea levels for scenarios A1B (red) and B1 (yellow) relative to the period 1981 - 2000 from the five-member ensemble
The shaded areas are the ranges of the members.
